- ProductsEmphasis is placed on introducing glass deep processing equipment that is synchronized with Europe, using glass deep processing equipment such as the Swiss Bystronic (Baichao) fully automatic mid air line, the Austrian LISEC
Customizable Sizes Low E Double Glazed Units UPVC Aluminum Window Replacement Glass Energy Star Compliant Thermal Break Design
We offer high-standard customization services to ensure each product meets your specific requirements, making us a trusted supplier for your architectural glass needs.
Dimensions: Customizable according to client requirements, OEM production supported
Thickness Range: Standard thicknesses include 5mm, 6mm, 8mm, 10mm, and 12mm; other thicknesses can be customized as per project needs
Color Options: Available in clear, gray, blue, green, and more; custom colors can be produced upon request
Processing Options: Edge finishing (grinding, polishing), coating, silk-screen printing, UV protection, and other treatments available
Description
| Thickness | 1mm-19mm | Structure | Solid, Hollow |
| Shape | Flat | Usage | Curtain Wall, Balustrades & Handrails |
| Application | Courtyard, Leisure Facilities | After-sale Service | Other |
| Project Solution Capability | Others | Product Type | Replacement Low-E IGU for UPVC / Aluminum Windows |
| Configuration | 4+12A+4 / 4+14A+4 / 4+16A+4 | Low-E Coating | Soft coat, position 3 |
| U-Value | ≤1.4 W/(m²-K) | SHGC | 0.30–0.50 |
| VLT | 70%–78% | Energy Star | Compliant (Northern zone applicable) |
| Spacer | Aluminum or warm edge | Edge Seal | PIB + silicone dual seal |
| Overall Thickness | 20mm / 22mm / 24mm |
Customization Process
Step 1: Requirement Communication
The client provides project requirements, dimensions, thickness, color, and any special processing needs to ensure the product meets expectations.
Step 2: Design Plan
We create a customization plan based on client requirements and, if needed, provide design drawings or sample confirmation.
Step 3: Quotation and Confirmation
We provide a detailed quotation, and upon client confirmation, sign a contract to finalize order details and delivery time.
Step 4: Production
The production phase begins with glass cutting, processing, and treatments strictly following the agreed specifications to ensure quality.
Step 5: Quality Check and Packaging
After production, we conduct a thorough quality check and package the approved products to prevent damage during transportation.
Step 6: Delivery and After-Sales
Products are shipped as scheduled, with after-sales support available for any further assistance needed by the client.
